CAPI powered TALOS clusters on Rackspace OpenStack Flex
We detail how to build immutable, secure, and minimal Kubernetes clusters by combining Cluster API (CAPI) with TALOS OS. This powerful stack allows you to leverage the cloud-agnostic management capabilities of CAPI while benefiting from TALOS's minimal attack surface. Deploying on RackSpace OpenStack Flex grants you complete control over your underlying infrastructure, maximizing resource efficiency and providing a production-ready cloud-native environment. This integration simplifies day-2 operations and delivers enterprise-grade security for your private cloud.
Preparing the Management Cluster
Note
For creating management clusters - In this case - we are going to make use of flex management cluster's namespace.
- Build TALOS image with desired options: https://factory.talos.dev
-
For the purpose of this blog and environment, following options were chosen:
- Hardware Type: Cloud Server
- Talos Linux Version: 1.11.1
- Cloud: Openstack
- Machine Architecture: amd64
- System Extensions: none
- Customization: none
-
Fetch the image on your RackSpace Openstack Flex environment :
wget https://factory.talos.dev/image/376567988ad370138ad8b2698212367b8edcb69b5fd68c80be1f2ec7d603b4ba/v1.11.1/openstack-amd64.raw.xz
- De-compress the image:
- Convert the image to qcow2 :
Note
If qemu-img isnt installed, one can install the same using: sudo apt-get install libguestfs-tools
qemu-img convert -f raw \
-O qcow2 openstack-amd64.raw talos-v1.11.1.qcow2
Upload to glance:
openstack image create \
--progress \
--disk-format qcow2 \
--container-format bare \
--file ./talos-v1.11.1.qcow2 \
--property hw_vif_multiqueue_enabled=true \
--property hw_qemu_guest_agent=yes \
--property hypervisor_type=kvm \
--property img_config_drive=optional \
--os-cloud image-services \
--public \
Talos-v1.11.1
Install K-ORC (needed for CAPO >=v0.12)
K-ORC is a Kubernetes API for declarative management of OpenStack resources. By fully controlling the order of OpenStack operations, it allows consumers to easily create, manage, and reproduce complex deployments. ORC aims to be easily consumed both directly by users, and by higher level controllers. ORC aims to cover all OpenStack APIs which can be expressed declaratively.
kubectl apply -f https://github.com/k-orc/openstack-resource-controller/releases/latest/download/install.yaml
Output
namespace/orc-system created
customresourcedefinition.apiextensions.k8s.io/flavors.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/floatingips.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/images.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/networks.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/ports.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/projects.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/routerinterfaces.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/routers.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/securitygroups.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/servergroups.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/servers.openstack.k-orc.cloud created
customresourcedefinition.apiextensions.k8s.io/subnets.openstack.k-orc.cloud created
serviceaccount/orc-controller-manager created
role.rbac.authorization.k8s.io/orc-leader-election-role created
clusterrole.rbac.authorization.k8s.io/orc-image-editor-role created
clusterrole.rbac.authorization.k8s.io/orc-image-viewer-role created
clusterrole.rbac.authorization.k8s.io/orc-manager-role created
clusterrole.rbac.authorization.k8s.io/orc-metrics-auth-role created
clusterrole.rbac.authorization.k8s.io/orc-metrics-reader created
rolebinding.rbac.authorization.k8s.io/orc-leader-election-rolebinding created
clusterrolebinding.rbac.authorization.k8s.io/orc-manager-rolebinding created
clusterrolebinding.rbac.authorization.k8s.io/orc-metrics-auth-rolebinding created
service/orc-controller-manager-metrics-service created
deployment.apps/orc-controller-manager created
- Enable clusterctl to add openstack provider (This is required for non-TALOS based images):
Note
Its assumed that clusterctl is pre-installed. If not - one can refer to these instructions
Output
Fetching providers
Skipping installing cert-manager as it is already installed
Installing provider="cluster-api" version="v1.10.4" targetNamespace="capi-system"
Installing provider="bootstrap-kubeadm" version="v1.10.4" targetNamespace="capi-kubeadm-bootstrap-system"
Installing provider="control-plane-kubeadm" version="v1.10.4" targetNamespace="capi-kubeadm-control-plane-system"
Installing provider="infrastructure-openstack" version="v0.12.4" targetNamespace="capo-system"
Your management cluster has been initialized successfully!
- You can now create your first workload cluster by running the following:
Clusterctl enablement specific for TALOS
CAPI has bootstrap and controlplane provider support for TALOS: - CACPPT repo - CABPT repo
Output
talos BootstrapProvider https://github.com/siderolabs/cluster-api-bootstrap-provider-talos/releases/latest/ bootstrap-components.yaml
talos ControlPlaneProvider https://github.com/siderolabs/cluster-api-control-plane-provider-talos/releases/latest/ control-plane-components.yaml
openstack InfrastructureProvider https://github.com/kubernetes-sigs/cluster-api-provider-openstack/releases/latest/ infrastructure-components.yaml
Output
Creating Workload Clusters
Note
For creating management clusters - In this case - we are going to make use of flex management cluster's namespace.
Create talos-cluster namespace
Create clouds.yaml file using project credentials
clouds:
default:
auth:
auth_url: https://<keystone_public_url>/v3
project_name: <project name>
project_domain_name: <Project domain name>
username: <username>
password: <password>
user_domain_name: <User domain name>
interface: public
region_name: <Region name>
identity_api_version: "3"
Now let's create a secret and label it using below commands:
kubectl create secret generic talos-demo-cloud-config --from-file=clouds.yaml='clouds.yaml' --from-literal=cacert="" -n talos-cluster
Below is the talos.yaml manifest which we will be using to create our k8s workload cluster:
---
apiVersion: cluster.x-k8s.io/v1beta1
kind: Cluster
metadata:
name: talos-cluster
namespace: talos-cluster
spec:
clusterNetwork:
pods:
cidrBlocks:
- 192.168.0.0/16
serviceDomain: cluster.local
controlPlaneRef:
apiVersion: controlplane.cluster.x-k8s.io/v1alpha3
kind: TalosControlPlane
name: talos-cluster-control-plane
infrastructureRef:
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: OpenStackCluster
name: talos-cluster
---
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: OpenStackCluster
metadata:
name: talos-cluster
namespace: talos-cluster
spec:
disableAPIServerFloatingIP: false
externalNetwork:
# adjust to the elastic IPs network id in the openstack project
id: 158704f8-4de4-42f7-8a2a-704c3427aa6e
managedSubnets:
- cidr: 10.6.0.0/24
dnsNameservers:
- 8.8.8.8
- 8.8.4.4
identityRef:
cloudName: default
name: talos-demo-cloud-config
managedSecurityGroups:
allNodesSecurityGroupRules:
- description: Created by cluster-api-provider - Talos API nodes
direction: ingress
etherType: IPv4
name: Talos-API-NODES
portRangeMax: 50001
portRangeMin: 50000
protocol: tcp
remoteIPPrefix: "0.0.0.0/0"
- description: Created by cluster-api-provider - Talos API LB
direction: ingress
etherType: IPv4
name: Talos-API-LB
portRangeMax: 50000
portRangeMin: 50000
protocol: tcp
# this means the talosctl control port is open to the world
# adjust as seen fit
remoteIPPrefix: "0.0.0.0/0"
- description: Created by cluster-api-provider - ICMP Echo Request/Reply ingress
direction: ingress
etherType: IPv4
name: ICMP-Echo-ingress
protocol: icmp
portRangeMin: 8
portRangeMax: 0
remoteManagedGroups:
- controlplane
- worker
- description: Created by cluster-api-provider - ICMP Echo Request/Reply egress
direction: egress
etherType: IPv4
name: ICMP-Echo-egress
protocol: icmp
portRangeMin: 8
portRangeMax: 0
remoteManagedGroups:
- controlplane
- worker
---
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: OpenStackMachineTemplate
metadata:
name: talos-cluster-control-plane
namespace: talos-cluster
spec:
template:
spec:
flavor: gp.8.4.8
image:
filter:
name: Talos-v1.11.1
---
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: OpenStackMachineTemplate
metadata:
name: talos-cluster-md-0
namespace: talos-cluster
spec:
template:
spec:
flavor: gp.8.4.8
image:
filter:
name: Talos-v1.11.1
---
apiVersion: bootstrap.cluster.x-k8s.io/v1alpha3
kind: TalosConfigTemplate
metadata:
name: talos-cluster-md-0
namespace: talos-cluster
spec:
template:
spec:
generateType: join
configPatches:
- op: replace
path: /machine/install/disk
value: /dev/vda
# adjust to your talos version
talosVersion: 1.11.1
---
apiVersion: cluster.x-k8s.io/v1beta1
kind: MachineDeployment
metadata:
name: talos-cluster-md-0
namespace: talos-cluster
spec:
clusterName: talos-cluster
# adjust to the desired number of worker nodes
replicas: 1
selector:
matchLabels: null
template:
spec:
bootstrap:
configRef:
apiVersion: bootstrap.cluster.x-k8s.io/v1alpha3
kind: TalosConfigTemplate
name: talos-cluster-md-0
clusterName: talos-cluster
infrastructureRef:
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: OpenStackMachineTemplate
name: talos-cluster-md-0
# adjust to the desired kubernetes version
version: v1.31.0
---
apiVersion: controlplane.cluster.x-k8s.io/v1alpha3
kind: TalosControlPlane
metadata:
name: talos-cluster-control-plane
namespace: talos-cluster
spec:
infrastructureTemplate:
kind: OpenStackMachineTemplate
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
name: talos-cluster-control-plane
namespace: talos-cluster
controlPlaneConfig:
controlplane:
generateType: controlplane
# adjust to the your talos version
talosVersion: 1.11.1
configPatches:
- op: replace
path: /machine/install/disk
value: /dev/vda
- op: add
# this is required to deploy the cloud-controller-manager
# which is responsible for running cloud specific controllers
path: /cluster/externalCloudProvider
value:
enabled: true
manifests:
- https://raw.githubusercontent.com/kubernetes/cloud-provider-openstack/master/manifests/controller-manager/cloud-controller-manager-roles.yaml
- https://raw.githubusercontent.com/kubernetes/cloud-provider-openstack/master/manifests/controller-manager/cloud-controller-manager-role-bindings.yaml
- https://raw.githubusercontent.com/kubernetes/cloud-provider-openstack/master/manifests/controller-manager/openstack-cloud-controller-manager-ds.yaml
# adjust to the desired number of control planes (kubernetes master nodes)
replicas: 1
# adjust to the desired kubernetes version
version: v1.31.0
Now let's apply this manifest to create our workload cluster.
Output
cluster.cluster.x-k8s.io/talos-cluster created
openstackcluster.infrastructure.cluster.x-k8s.io/talos-cluster created
openstackmachinetemplate.infrastructure.cluster.x-k8s.io/talos-cluster-control-plane created
openstackmachinetemplate.infrastructure.cluster.x-k8s.io/talos-cluster-md-0 created
talosconfigtemplate.bootstrap.cluster.x-k8s.io/talos-cluster-md-0 created
machinedeployment.cluster.x-k8s.io/talos-cluster-md-0 created
taloscontrolplane.controlplane.cluster.x-k8s.io/talos-cluster-control-plane created
After 2-3 mins, we can verify our workload cluster has been created. Extract the kubeconfig using clusterctl command and try to create a pod in it to confirm that our workload k8s cluster is functional.
Get the status of the various components using below commands
Check OpenStackCluster resource
Output
Get the status of the Cluster resource
Get the status of the TalosControlPlane resource
kubectl get -n talos-cluster taloscontrolplane.controlplane.cluster.x-k8s.io/talos-cluster-control-plane
Output
Extract the kubeconfig for the workload cluster
Get the status of the MachineDeployment resource
Output
Get more details of the nodes
Output
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
talos-cluster-control-plane-5jr7r Ready control-plane 9m34s v1.31.0 10.6.0.39 <none> Talos (v1.10.6) 6.12.40-talos containerd://2.0.5
talos-cluster-md-0-ltdrq-zkld4 Ready <none> 9m28s v1.31.0 10.6.0.118 <none> Talos (v1.10.6) 6.12.40-talos containerd://2.0.5
Get the status of the pods in kube-system namespace
Output
NAME READY STATUS RESTARTS AGE
coredns-958d7d544-4p5hw 1/1 Running 0 10m
coredns-958d7d544-h7fjz 1/1 Running 0 10m
kube-apiserver-talos-cluster-control-plane-5jr7r 1/1 Running 0 9m48s
kube-controller-manager-talos-cluster-control-plane-5jr7r 1/1 Running 2 (10m ago) 9m2s
kube-flannel-gbtpl 1/1 Running 0 9m58s
kube-flannel-mxgzj 1/1 Running 0 10m
kube-proxy-frjfg 1/1 Running 0 9m58s
kube-proxy-ppcw8 1/1 Running 0 10m
kube-scheduler-talos-cluster-control-plane-5jr7r 1/1 Running 2 (10m ago) 8m55s
Create a nginx pod to verify the workload cluster functionality
Output
Warning: would violate PodSecurity "restricted:latest": allowPrivilegeEscalation != false (container "nginx" must set securityContext.allowPrivilegeEscalation=false), unrestricted capabilities (container "nginx" must set securityContext.capabilities.drop=["ALL"]), runAsNonRoot != true (pod or container "nginx" must set securityContext.runAsNonRoot=true), seccompProfile (pod or container "nginx" must set securityContext.seccompProfile.type to "RuntimeDefault" or "Localhost")
pod/nginx created
Get the status of the pods
Output
Check OpenStack resources
The k8s cluster resources can also be seen as newly created Virtual Machines, Networ, using:
Interacting with TALOS nodes using talosctl
Now let's get the talosconfig secret from talos-cluster namespace in our management cluster so that we can run some of talosctl commands.
kubectl get secret talos-cluster-talosconfig -n talos-cluster -o jsonpath="{.data.talosconfig}" | base64 -d > taclosconfig.new
Following talosctl commands can be run to interact with the TALOS cluster. TALOS by default does not allow SSH for security reasons, adhering to the least-priviledge principle.
Info
In below commands: -e : Endpoint viz. FloatingIP of the control plane VM. -n : Node IP which are master/worker nodes in the cluster.
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 204.232.x.x get disks
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 10.22.0.226 mounts
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 10.22.0.226 cluster show
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 10.22.0.148 config info
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 10.22.0.148 containers
talosctl --talosconfig talosconfig.new -e 204.232.x.x -n 10.22.0.226 dashboard
